QS9D-F Connector Cable (Battery Power Harness)
High Current Grade | For Drones/UAVs/EV/Lithium Battery
Connector: QS9D Female
Conductor: Gold Plated/Tinned Pure Copper
Wire: 6AWG Silicone Wire (15cm)
Rated Current: 180A (Continuous), 240A (Instantaneous)
Rated Voltage: 500V DC
Temp: -20℃ ~ +120℃
Certifications: RoHS, REACH, CE Compliant
Customizable: Wire Length/End Treatment/OEM ODM
QS9D-F Connector Cable (Battery Power Harness) Specifications
High Current Grade Connector Cable Specifications, Compliant with International Standards, Suitable for RC Drones, Agricultural UAVs, EV Cars & Lithium Battery Systems
1. Basic Specifications
Product Name: QS9D-F Connector Cable / Battery Power Harness / Drone UAV Power Lead
Connector: QS9D-F Connector
Rated Current: 180A (Continuous), 240A (Instantaneous)
Rated Voltage: 500V DC
Conductor Material: Tinned/ Gold Plated Pure Copper
Wire Material: 6AWG Silicone Wire (Tinned End Stripped Lead)
Wire Length: 15cm / 150mm
Insulation & Jacket Material: Silicone (Wear-Resistant, High-Temp Resistant)
Rated Temperature Range: -20℃ ~ +120℃
Wire Gauge: 6AWG
Flex Life: ≥100000 Cycles
2. Key Performance Parameters
Current-Carrying Capacity: 180A Continuous, 240A Instantaneous, Low Conductor Resistance, Stable High-Current Power Transmission
Environmental Resistance: High-Temperature Resistant, Anti-Humidity, Anti-Oxidation, Adapt to Outdoor & Harsh Drone/UAV Operating Environments
Insulation Resistance: Excellent Insulation Performance, Safe for High-Voltage Lithium Battery Applications
Certifications: Compliant with RoHS, REACH, CE Standards (Industrial Grade)
3. Structural Features
Stranded Copper Conductor: High-Purity Tinned/Gold-Plated Copper, Low Resistance, High Conductivity, Durable for High-Current Use
Silicone Wire Jacket: Soft & Flexible Silicone Insulation, High-Temp Resistant, Anti-Aging, Easy to Install in UAV/Drone Systems
QS9D-F Connector: Gold-Plated Copper Contacts, High Current Rating, Secure Connection, Anti-Arc & Anti-Loosening Design
Stripped & Tinned End: Pre-Stripped & Tinned Lead, Easy Solder/Connection to Battery or ESC Terminals
4. Application Scope
Widely Used for RC Drones, Agricultural UAVs, Electric Vehicles, Lithium Battery Packs, and Other Scenarios Requiring High-Current, Stable Power Transmission.
5. Customization Options
Custom Wire Gauge (Optional)
Custom Wire Length, Custom Connector Gender/Type
Custom Tinned/Stripped End Specifications
OEM/ODM Service Accepted
