QS2--15A

QS2 High-Current Anti-Spark Connector

Industrial Grade | For New Energy/EV/Storage/Drones

Rated Current: 15A

Rated Voltage: 500V DC

Rated Temp: -20°C ~ 120°C

Conductor: Gold-Plated Copper

Sheath: PA66

Contact Resistance: ≤0.51mΩ

Flame Retardant: UL94-V0

Customizable: N/A (Standard Spec)

1. Basic Specifications

   Product Name: QS2 High-Current Anti-Spark Connector

   Rated Current: 15A

   Rated Voltage: 500V DC

   Rated Temperature: -20°C ~ 120°C

   Conductor Material: Gold-Plated Copper

   Sheath Material: PA66

   Contact Resistance: Max 0.51mΩ

   Flame Retardant Grade: UL94-V0
2. Key Performance Parameters

   Anti-Spark Function: Built-in anti-spark design to prevent arc during connection/disconnection

   Environmental Resistance: Wide temperature range, suitable for various working conditions

   Electrical Performance: Low contact resistance, stable current transmission

   Safety Performance: UL94-V0 flame retardant grade, meets fire safety requirements
3. Structural Features

   Gold-Plated Copper Conductor: Low contact resistance, high conductivity, anti-oxidation

   PA66 Sheath: High strength, impact-resistant, flame retardant

   Compact Design: Easy to install and use, reliable connection
4. Application Scope

   Specially designed for new energy and small-sized power equipment such as electric motorcycles, electric vehicles, energy storage lithium batteries and industrial drones.
